MEAN WELL SLD-50-24 230V / 24Vdc 2,1A 50,4W
Code: 8505024
Product detailed description
- 50.4W power output
- Wide AC input range / Full range (120~305VAC)
- Constant voltage + constant current mode (or constant power mode for 56V model)
- Short circuit / overcurrent / overvoltage / overtemperature protection
- Slim and low profile compact plastic enclosure (Class II power unit)
- Passive cooling (free air convection)
- No load power consumption less than 0.5 W (for 12V/24V models)
- Built-in active PFC function
- High reliability and high efficiency up to 93%
- Case operating temperature (Tcase) -25°C to +85°C
- Weight: 175g
- 5-year warranty
Additional parameters
| Category: | Power supplies for LED technologies |
|---|---|
| Weight: | 0.175 kg |
| Input voltage: | 230 V |
| Degree of IP protection: | 50 |
| Warranty period in months: | 36 |
| Dimension height: | 16,8 mm |
| Dimension length: | 280 mm |
| Dimension width: | 30 mm |
| Total power / input: | 50,4 W |
| Output voltage: | 24 V |
| Output current: | 2100 mA |
| Switching power supply control type: | neřízený |
| U / I power supply method: | U |
| Cutting to size - sheets: | No |
| Cutting to size - profiles: | No |
| Availability: | In stock |
